Relé de retardo de tiempo, 12VDC, 10A, DPDT, 3 segundos.
| Item - Relay | Single Function Timing Relay |
|---|---|
| Function - Timing Relay | Interval On |
| Coil Volts | 12V DC |
| AC Contact Rating - Relay | 10A @ 240V |
| DC Contact Rating - Relay | 10 A @ 30 V |
| Base Type - Plug In Relay | Octal |
| Number of Pins - Relay | 8 |
| Adjustment Method - Timer | Potentiometer |
| Mounting - Relay | Plug In |
| Min. Time Setting - Timer | 3 sec |
| Contact Form - Relay | DPDT |
| Max. Time Setting - Timer | 5 min |
| Power Consumption - Relay | 2 W |
| Function | Interval On |
| Item | Single Function Time Delay Relay |
| Contact Amp Rating (Resistive) | 10 A |
| Socket | 1EGP3, 1EGP5, 5X852 |
| Body Height - Relay | 2.9 in |
| Base Type | Octal |
| Contact Form | DPDT |
| Hz | 50/60 |
| Socket Code | A |
| Standards | CE Certified, CSA Certified, UL Listed, UL Socket |
| Operating Functions | 4 |
| Coil Rating | 2 W |
| Mounting | plug In |
| Status Indicator | None |
| Body Width - Relay | 2.4 in |
| Hz - Electrical | 50 Hz, 60 Hz |
| Max. Time Setting | 5 min |
| Pins | 8 |
| Overall Height - Relay | 3.1 in |
| Electrical Connection | Socket |
| Adjustment Method | Potentiometer |
| Contact Material | Silver Nickel |
| Min. Time Setting | 3 sec |
| Body Depth - Relay | 1.7 in |
| Input Voltage | 12V DC |
| Minimum Time Setting | 3 sec |
| Contact Rating (AC) | 10 A @ 240 V |
| Overall Depth | 3.1 in |
| Coil Voltage | 12V DC |
| Body Width | 2.4 in |
| Body Height | 2.9 in |
| Reset Method | Time-Limit Reset |
| Sealing | Enclosed |
| Delay Function | Interval On |
| Body Depth | 1.7 in |
| Current Rating | 10 A |
| Maximum Time Setting | 5 min |
| Number of Delay Functions | 1 |
| Frequency | 50/60 Hz |
| Base Shape | Octal |
| Power Consumption | 2 W |
| Number of Pins | 8 |
| Mounting Style | Plug-In |
| Contact Rating (DC) | 10 A @ 30 V |
| Flat Pin Width | Not Applicable |
| IP Rating | IP20 |
| Package Quantity | 1 |
