Gate Hinge, Stainless Steel, Screw-On Mounting, 3 1/8 in Leaf W x 3 1/2 in Leaf H
| Corners | Round |
|---|---|
| Door Leaf Height | 3-1/2 in |
| Door Leaf Thickness | 0.13 in |
| Door Leaf Width | 3-1/8 in |
| Finish | Marine Grade Powder Coated |
| Holes per Leaf | 8 |
| Load Capacity | 66 lb |
| Material | Stainless Steel |
| Mounting | Screw-On |
| Range of Motion | 180 deg |
| Required Door Thickness | 3 in |
| Features | Tension-Adjustable Hinges |
| Height | 3-1/2 in |
| Item | Gate Hinge |
| Holes | With |
| Door Leaf Length | 3-1/2 in |
| Door Thickness | 3 in |
| Frame Leaf Width | 3-1/8 in |
| Width | 7 in |
| Color | Black |
| Hardware | Yes |
| Ligature Resistant | No |
| Frame Leaf Length | 3-1/2 in |
| Leaf Thickness | 0.13 in |
| Hinge Number | #2 |
| Frame Leaf Height | 3-1/2 in |
| Frame Leaf Thickness | 3-1/8 in |
| Overall Width | 7-3/8 in |
| Number of Holes per Leaf | 8 |
| Mounting Style | Full Surface |
| Range of Motion - Maximum | 180 deg |
| Includes Hardware | Hardware Included |
| Door Thickness - Minimum | 4 in |
| Corner Type | Round |
| ANSI/BHMA Finish | Sprayed, Suede Powder Coated |
| Country of Origin (subject to change) | Taiwan, Province of China |
| Package Quantity | 1 |
