Indexable Boring Bar, E02.5H-SCLDR-1.2, 4 in L, Carbide, 80 Degrees Diamond Insert Shape
| Item | Indexable Boring Bar |
|---|---|
| Overall Length | 4 in |
| Shank Material | Carbide |
| Insert Shape | 80 Degrees Diamond |
| ANSI Code | E02.5H-SCLDR-1.2 |
| Lead Angle | 12 Degrees |
| Type | Carbide Coolant-Thru |
| Width Offset | 0.093 in |
| Cutting Direction | Right Hand |
| Mounting Style | Screw Lock |
| Inscribed Circle | 0.1563 in |
| Shank | Round |
| Style | E02.5H-SCLDR-1.2 |
| Material | Carbide |
| Min. Bore | 0.175 in |
| Shank Dia. | 5/32 in |
| Insert Thickness | 0.4 in |
| Insert Size | 1.20.60.2 |
| Insert Screw | TS-18.35-1M1 |
| Rake | Negative |
| Vibration Dampening | Yes |
| Compatible Hardware | TS-18.35-1M1 Insert Torx Screw |
| Cutting Application | Boring |
| Features | Surface Finish Compared to Steel Boring Bars |
| Number of Coolant Holes | 1 |
| Min. Bore Dia. | 0.175 in |
| ISO Number | E02.5H-SCLDR-1.2 |
| Side Cutting Edge Angle | -5 deg |
| Number of Inserts | 1 |
| Coolant Fed | Coolant Through |
| Insert Inscribed Circle | 5/32 in |
| Insert Holding Type | Clamp |
| Center to Cutting Tip | 0.093 in |
| Insert Style | CDGT |
| Package Quantity | 1 |
