Tool Holder, OD/ID, QITP40N
| Series | QITP40N |
|---|---|
| Dimension D (In.) | 1-1/2 |
| Application | For Inner And Outer Diameter Threading Using Standard Carbide Inserts |
| Includes | TIH Cartridge for External Threading |
| Dimension C (In.) | 5.619 |
| Type | ID, OD |
| Dimension G (In.) | 1.493 |
| Dimension E (In.) | 2-1/4 |
| Dimension A (In.) | 1-1/2 |
| Dimension F (In.) | 3.023 |
| For Use With | QITP40N Tool Post |
| Item | Tool Post Holder |
| Features | Fits Industry Standard Tool Posts |
| Overall Width | 6.15 in |
| Overall Height | 2-1/2 in |
| Overall Length | 6-5/16 in |
| For Tool Post Type | QITP40N |
| Tool Post Holder Type | ID, OD |
| Holder Type | Outside and Inside Diameter Threading |
| Compatible Shank Size - Maximum | 3/8 in |
| Compatible Manufacturer Model Number | NL354-3R 0, QITP40N, TIH354-32 |
| Compatible Shank Size - Minimum | Not Applicable |
| Compatible Tool Type | Laydown Threading Insert Cartridges, Laydown Threading Inserts, On Edge Threading Insert Cartridges, On Edge Threading Inserts |
| Centerline Height - Maximum | 3.11 in |
| Tool Post Series | QITP40N |
| Package Quantity | 1 |
