3/8" Insert Inscribed Circle
| Thread Type | External |
|---|---|
| Hand of Holder | Left Hand |
| Shank Width/Diameter (Decimal Inch) | 1.5000 |
| Shank Width/Diameter (mm) | 38.10 |
| Shank Width/Diameter (Inch) | 1-1/2 |
| Toolholder Style | ADNS |
| Insert Compatibility | TopNotch NG to 4L |
| Insert Holding Method | Clamp |
| Shank Height (Decimal Inch) | 1.5000 |
| Shank Height (Inch) | 1-1/2 |
| Shank Length (Decimal Inch) | 5.6200 |
| Overall Length (mm) | 177.80 |
| Overall Length (Inch) | 7 |
| Overall Length (Decimal Inch) | 7.0000 |
| Multi-use Tool | Yes |
| Head Length (Decimal Inch) | 1.3800 |
| Maximum Depth of Cut (Decimal Inch) | 0.2900 |
| Back of Bar to Cutting Edge (Decimal Inch) | 1.7500 |
| Insert Inscribed Circle (Decimal Inch) | 0.3750 |
| Coolant Hole Thread Size (Inch) | 1/8 NPT |
| UNSPSC Code | 23291800 |
| Coolant Through | Yes |
| Series | DorNotch Jet-Stream |
| Country of Origin | UNITED STATES |
| MSC Number | MSC# 47140207 |
