1-3/4" Min Bore Dia, 3/8" Insert Inscribed Circle
| Thread Type | Internal |
|---|---|
| Hand of Holder | Right Hand |
| Shank Width/Diameter (Decimal Inch) | 1.2500 |
| Shank Width/Diameter (mm) | 31.75 |
| Shank Width/Diameter (Inch) | 1-1/4 |
| Toolholder Style | AS-ADNE |
| Insert Compatibility | TopNotch NG to 3L |
| Insert Holding Method | Clamp |
| Shank Height (Decimal Inch) | 1.2500 |
| Shank Height (Inch) | 1-1/4 |
| Overall Length (mm) | 254.00 |
| Overall Length (Inch) | 10 |
| Overall Length (Decimal Inch) | 10.0000 |
| Minimum Bore Diameter (Decimal Inch) | 1.7500 |
| Multi-use Tool | Yes |
| Center to Cutting Edge (Decimal Inch) | 0.8800 |
| Insert Inscribed Circle (Decimal Inch) | 0.3750 |
| Insert Inscribed Circle (Inch) | 3/8 |
| Coolant Hole Thread Size (Inch) | 1/8 NPT |
| UNSPSC Code | 23291800 |
| Coolant Through | Yes |
| Series | DorNotch Jet-Stream |
| Country of Origin | UNITED STATES |
| undefined | undefined |
| MSC Number | MSC# 47140199 |
