3/4 x 3/4" Shank, 4-1/2" OAL
| Toolholder Style | MSRN |
|---|---|
| Hand of Holder | Left Hand |
| Insert Compatibility | SN..43. |
| Insert Holding Method | Pin; Clamp |
| Shank Width (Inch) | 3/4 |
| Shank Height (Inch) | 3/4 |
| Overall Length (Decimal Inch) | 4.5000 |
| Coolant Through | No |
| Rake | Negative |
| Cutting Direction | Left Hand |
| Compatible Insert Size Code | SNM_432 |
| Rake Angle | -7 |
| Multi-use Tool | No |
| Shank Width (Decimal Inch) | 0.7500 |
| Shank Height (Decimal Inch) | 0.7500 |
| Series | Multi-Option |
| Overall Length (Inch) | 4-1/2 |
| Cutting Tool Application | Turning |
| Head Length (Decimal Inch) | 1.2500 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.8800 |
| Insert Inscribed Circle (Decimal Inch) | 0.5000 |
| Insert Inscribed Circle (Inch) | 1/2 |
| Toolholder Material | Steel |
| UNSPSC Code | 23153308 |
| Country of Origin | UNITED STATES |
| undefined | undefined |
| MSC Number | MSC# 08645475 |
