Turning Toolholder, CCMT, SCLCL06-2J, LH
| Item | Indexable Turning Toolholder |
|---|---|
| Type | CCMT Holder |
| Insert Shape | 80 Degrees Diamond |
| Torx Wrench | T-8 |
| Clamp Screw | TS-25.45-6M2 |
| Rake | Neutral |
| Shank | Square |
| Style | SCLCL06-2J |
| Insert Size | 21.51 |
| Overall Length | 3-1/2 in |
| Cutting Direction | Left Hand |
| Features | Hardened to 44 HRC |
| Insert Clearance Angle | 7 deg |
| Cutting Application | Turning |
| Shank Width | 3/8 in |
| Toolholder Style | SCLC |
| Insert Holding Type | Screw On |
| Shank Height | 3/8 in |
| Head Length | 1/2 in |
| Side Cutting Edge Angle | -5 deg |
| Insert Inscribed Circle | 1/4 in |
| Shank Material | Alloy Steel |
| ISO Number | SCLCL062J |
| ANSI Code | SCLCL062J |
| Cutting Height | 3/8 in |
| Insert Style | CCMT |
| Lead Angle | Negative 5 Degrees |
| Width Offset | 0.500 |
| Rake Angle | 0 deg |
| Mounting Style | Screw Lock |
| Inscribed Circle | 0.250 |
| Package Quantity | 1 |
