Turning Toolholder, TCMT, STNCR10-2A, RH
| Item | Indexable Turning Toolholder |
|---|---|
| Rake | Neutral |
| Shank | Square |
| Insert Shape | Triangle |
| Style | STNCR10-2A |
| Clamp Screw | TS-25.45-6M2 |
| Torx Wrench | T-8 |
| Type | TCMT Holder |
| Insert Size | 21.51 |
| Cutting Direction | Right Hand |
| Overall Length | 4 in |
| Insert Holding Type | Screw On |
| Cutting Height | 5/8 in |
| Toolholder Style | STNC |
| ISO Number | STNCR102A |
| ANSI Code | STNCR102A |
| Side Cutting Edge Angle | -3 deg |
| Head Length | 5/8 in |
| Cutting Application | Turning |
| Insert Style | TCMT |
| Insert Inscribed Circle | 1/4 in |
| Features | Hardened to 44 HRC |
| Shank Width | 5/8 in |
| Shank Material | Alloy Steel |
| Shank Height | 5/8 in |
| Insert Clearance Angle | 7 deg |
| Mounting Style | Screw Lock |
| Rake Angle | 0 deg |
| Inscribed Circle | 0.250" |
| Width Offset | 0.625" |
| Lead Angle | 3 Degrees |
| Package Quantity | 1 |
