Differential pressure gage, range 0-25" w.c., minor divisions .50.
| Differential Pressure Gauge Type | Differential Pressure Gauge |
|---|---|
| Gauge Nominal Dial Size | 4 in |
| Basic Gauge Case Material | Metal |
| Differential Gauge Connection Type | FNPT |
| Differential Gauge Connection Size | 1/8 in |
| Gauge Connection Location | Back, Side |
| Differential Pressure Range Units | in wc |
| Differential Pressure Range Value | 0 to 25 |
| Gauge Accuracy | +/-2% |
| Item | Differential Pressure Gauge |
| Scale Type | Pressure |
| Body Material | Die Cast Aluminum |
| Dial Material | Die Cast Aluminum |
| Gauge Operating Temp. Range | 20 to 140 deg F |
| Rated Total Pressure | -20 in Hg to 15 psi |
| Differential Pressure Range | 0 to 25 in wc |
| Includes | Instructions, Three Mounting Adapters with Screws, Two 1/8 in NPT Plugs, Two 1/8 in NPT to 3/16 in ID Rubber Tubing Adapters |
| Gauge Primary Range Smallest Graduation | 0.5 |
| Manufacturers Warranty Length | 1 yr |
| Case Material | Aluminum |
| Standards | EU Directive 2011/65/EU (RoHS II) |
| Series | 2000 |
| Case Color | Gray |
| Ambient Operating Temperature Range | 20 to 140 deg F |
| Mounting Hardware Included | Flange |
| Maximum Working Static Pressure | 80 psig |
| IP/NEMA Rating | IP67 |
| Process Connection Size | 1/8 in |
| Compatible Process Media | Cleanroom |
| Bezel Material | Die Cast Aluminum |
| Non-Sparking | No |
| Process Connection Type | NPT |
| Application | Flow Measurement, Vacuum Applications, Clean Rooms, HVAC/R, Fan Pressure Indication, Filtration Monitoring |
| Case Construction | Corrosion Resistant |
| Mounting Orientation | Upright Only |
| Adjustable Set Points | No |
| Over-Pressure Limit | 1.72 bar |
| Case Shape | Round |
| Accuracy Details | +/-2% (-HA model +/-1) of FS ( +/-3% (-HA +/-1.5%) on -0, -100PA, -125PA, -10MM and +/-4% (-HA +/-2%) on -00, -60PA, -6MM ranges), throughout range at 70 Degrees F (21.1 Degrees C). |
| Hazardous Location Rating | Not Rated |
| Process Connection Location | Back, Side |
| Bezel Mounting Type | Flush |
| Bolt Circle Diameter | 4-1/8 in |
| Manufacturer Warranty Length | 5 yr |
| Includes Calibration Certificate | No |
| Panel Mount Characteristics | 3 L Dia Holes on E Dia Bolt Circle |
| Sensor Type | Diaphragm |
| Nominal Dial Size | 4 in |
| Sensor Material | Silicone Rubber |
| Pressure Gauge Type | Differential Pressure Gauge |
| Pointer Characteristics | Red Tipped Pointer of Heat Treated Aluminum Tubing is easy to see |
| Accuracy | +/-2.00% |
| Process Connection Gender | Female |
| Blowout Safety Back | Yes |
| Housing Material | Die Cast Aluminum |
| Removable Bezel | No |
| Case Finish | Die Cast |
| Gauge Case Material | Aluminum |
| Pointer Material | Aluminum |
| Case Diameter | 4-3/4 in |
| Case Depth | 1.687 in |
| Dial Face Material | Plastic |
| Includes Vent Plug | Yes |
| Dial Color | White |
| Panel-Mountable | Yes |
| Includes Mounting Hardware | Yes |
| Pressure Range | 0 to 25 in wc |
| IP Rating | IP67 |
| Pressure Measurement - Maximum | 25 in wc |
| Number of Switches | 0 |
| Operating Temperature - Maximum | 140 deg F |
| Operating Temperature - Minimum | 20 deg F |
| Pressure Measurement - Minimum | 0 in wc |
| Working Static Pressure - Maximum | 80 psig |
| Package Quantity | 1 |
