Transmisor de presión digital, interruptor, Dpt 01000 PSI, salida de 4-20 mA.
| Loop Resistance | DPT-A: ≤ 0.5k; DPT-V: > 10k. |
|---|---|
| Accuracy | 1.0% F.S. (includes non-linearity, hysteresis, zero point). |
| Features | Dual PNP solid state switches; 14-segment red LED display; User-friendly, intuitive 3-key operation; Rotating design: 330° display rotation; 180° display electronic rotation |
| Housing | 316 L lower body, heat and chemical resistant fiberglass reinforced plastic (PBT) plastic head, TPE-E keyboard, PC display window. |
| Display | Red LED 4-digit (0.35" H digits). |
| Electrical Connections | M 12x1, 5-pin. |
| Wetted Materials | Pressure connection: 316 L SS; Pressure sensor: 316 L SS (13-8 PH for ranges above 150 psi). |
| Thermal Effect | 0.2% FS / 10k. |
| Output Signal | DPT-A: 4 to 20 mA; DPT-V: 0 to 10 VDC. |
| Agency Approvals | CE. |
| Power Requirements | 15 to 35 VDC. |
| Enclosure Rating | IP67. |
| Temperature Limits | 32 to 176°F (0 to 80°C). |
| Switch Type | PNP. |
| Service | Compatible gases, liquids or vapors. |
| Power Consumption | ≤ 100 mA. |
| Process Connections | 1/4" male NPT. |
| Mounting Orientation | Mount in any position. |
| Electrical Rating | 250 mA. |
| Package Quantity | 1 |
