Control de límite de termopar, entrada tipo J/K/S, 230 V, grados Celsius.
| Accuracy | ±1% FS. |
|---|---|
| Temperature Limits | >Ambient: 32 to 150°F (0 to 65°C); Storage: -4 to 176°F (-20 to 80°C). |
| Memory Backup | Nonvolatile memory. |
| Agency Approvals | CE, FM, cURus. |
| Power Consumption | 4 VA. |
| Display | 3-digit, red, 1/2" (12.7 mm) digits, plus sign. |
| Output | SPDT relay rated 16 A @ 240 VAC resistive. |
| Features | FM approved temperature limiting control; Integral and remote reset capabilities |
| Power Requirements | 115 VAC, 230 VAC, 12 VAC/VDC or 24 VAC/VDC (depending on model). |
| Front Panel Rating | IP64. |
| Package Quantity | 1 |
