Ceramic Fuse, CEO Series, Fast-Acting, 40A, 550V AC, 80kA at 550V AC
| Series | CEO |
|---|---|
| Speed | Fast-Acting |
| Amps | 40A |
| AC Voltage Rating | 550V AC |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 80kA at 550V AC |
| Body Style | Bolt-On |
| Diameter | 24.5 mm |
| Length | 110 mm |
| Body Material | Ceramic |
| Equivalent Brand and Series | Bussmann CEO |
| DC Voltage Rating | Not Rated |
| Item | Ceramic Fuse |
| Green Environmental Attribute | RoHS 2011/65/EU Compliant |
| Fuse Speed | Fast Acting |
| Rejection / Nonrejection | Nonrejection |
| Element | Single |
| Standards | BS88 & IEC Part 1, CE, IEC 60269-1 |
| Equivalent Series | CEO |
| Length (Straight Wireway) | 110 mm |
| Weight | 77.6 g |
| Package Quantity | 1 |
