Ceramic Fuse, D125 Series, Time-Delay, 100A, 500V AC, 50kA at 500V AC
| Series | D125 |
|---|---|
| Speed | Time-Delay |
| Amps | 100A |
| AC Voltage Rating | 500V AC |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 50kA at 500V AC |
| Body Style | Cylindrical |
| Diameter | 1-1/3 in |
| Length | 2-1/4 in |
| Body Material | Ceramic |
| Equivalent Brand and Series | Bussmann D125, Siemens 5SC2 |
| DC Voltage Rating | Not Rated |
| Item | Ceramic Fuse |
| Element | Dual |
| Standards | DIN 49515, IEC 60269 |
| Class | D |
| Color Code | Red |
| Green Environmental Attribute | RoHS 2011/65/EU Compliant |
| IEC Operating Fuse Class | gG, gL |
| Class D Fuse Size | DIV |
| Cap Diameter | 9/32 in |
| Equivalent Series | 5SC2, D125 |
| Weight | 115.3 g |
| Mounting | Holder |
| Package Quantity | 1 |
