Ceramic Fuse, D16 Series, Fast-Acting, 4A, 500V AC, 50kA at 500V AC
| Series | D16 |
|---|---|
| Speed | Fast-Acting |
| Amps | 4A |
| AC Voltage Rating | 500V AC |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 50kA at 500V AC |
| Body Style | Cylindrical |
| Diameter | 1/2 in |
| Length | 2 in |
| Body Material | Ceramic |
| Equivalent Brand and Series | Bussmann D16, Siemens 5SA2 |
| DC Voltage Rating | Not Rated |
| Item | Ceramic Fuse |
| Rejection / Nonrejection | Nonrejection |
| Class | D |
| Color Code | Brown |
| Green Environmental Attribute | RoHS 2011/65/EU Compliant |
| Standards | DIN 49520, IEC 60269 |
| Element | Single |
| Fuse Speed | Fast Acting |
| Cap Diameter | 15/64 in |
| IEC Operating Fuse Class | gG, gL |
| Equivalent Series | 5SA2, D16 |
| Class D Fuse Size | DI |
| Length (Straight Wireway) | 2 in |
| Weight | 0.352 lb |
| Package Quantity | 1 |
