Ceramic Fuse, NSD Series, Time-Delay, 36A, 415V AC, 80kA at 415V AC
| Series | NSD |
|---|---|
| Speed | Time-Delay |
| Amps | 36A |
| AC Voltage Rating | 415V AC |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 80kA at 415V AC |
| Body Style | Blade |
| Diameter | 11/16 in |
| Length | 1-5/16 in |
| Body Material | Ceramic |
| DC Voltage Rating | Not Rated |
| Item | Ceramic Fuse |
| Standards | BS88 & IEC Part 1 & 2, CE, IEC 60269-1 |
| Class | Not Rated |
| Element | Dual |
| Weight | 0.0357 lb |
| Package Quantity | 1 |
