Ceramic Fuse, NZ Series, Fast-Acting, 50A, 400V AC, 50kA at 400V AC
| Series | NZ |
|---|---|
| Speed | Fast-Acting |
| Amps | 50A |
| AC Voltage Rating | 400V AC |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 50kA at 400V AC |
| Body Style | Cylindrical |
| Diameter | 19/32 in |
| Length | 1-27/64 in |
| Body Material | Ceramic |
| Equivalent Brand and Series | Bussmann NZ |
| DC Voltage Rating | 250V DC |
| Item | Ceramic Fuse |
| Color Code | White |
| Rejection / Nonrejection | Nonrejection |
| Standards | DIN 49538, IEC 60269 |
| Element | Single |
| Class | D |
| Fuse Speed | Fast Acting |
| Class D Fuse Size | D02 |
| Cap Diameter | 15/64 in |
| Equivalent Series | NZ |
| IEC Operating Fuse Class | gG, gL |
| Length (Straight Wireway) | 1-27/64 in |
| Mounting | Holder |
| Weight | 36 g |
| Package Quantity | 1 |
