Fuse Holder, 3 Poles, 0 to 30A Amp Range, 600V AC/DC Volt Rating
| Item | Fuse Holder |
|---|---|
| Series | JP |
| Number of Poles | 3 |
| Amp Range | 0 to 30A |
| Voltage Rating | 600V AC/DC |
| Fits Fuse Type | Industrial |
| Connector Type | Pressure Plate |
| Mounting Style | Panel |
| Visual Indication | Non-Indicating |
| Spring Reinforced Clip | Yes |
| Wire Range | 14 AWG to 10 AWG |
| Fuse Block Design | Open Pyramid |
| Body Material | Thermoplastic |
| Width | 3.29 in |
| Length | 3-3/4 in |
| Height | 2.78 in |
| For Fuse Series | LPJ, JKS |
| Features | Space Saving Design |
| Fuse Block or Fuse Holder Type | Fuse Block |
| Fuse UL Class | J |
| Standards | CE, CSA Certified, UL Listed |
| Fuse Type | Industrial |
| For Use With | For use with LPJ, DFJ, JKS fuse |
| For Fuse Size | 2-1/4 in L x 13/16 in dia |
| Short Circuit Current (KA) | 200 kA |
| Weight | 0.753 lb |
| For Fuse Class | J |
| Max. Amps | 30 |
| Fits Fuse Block Style | Non-Rejection |
| Max. Voltage | 600V AC/DC |
| Package Quantity | 1 |
