Botón pulsador iluminado 1Nc 4 A @ 24 Vac
| Size | 22.5 mm |
|---|---|
| Bezel | Silver |
| Series | C22 |
| Type | Compact pushbutton |
| Operating mode | Momentary |
| Light unit voltage | 24 Vac/dc |
| Actuator Color | Red |
| Mounting method | Flush |
| Operating cycles | 5 million |
| Illumination | Illuminated |
| Actuator function | Momentary |
| Contact configuration | 1 NC |
| Actuator Material | Plastic |
| Product Height | 1.18 in |
| Degree of protection | NEMA 4X |
| Enclosure | IP67 |
| Certifications | EN 60947 |
| Product Width | 1.18 in |
| Compliances | DIN VDE 0600 |
| Product Length/Depth | 22.09 in |
| Light unit type | LED |
| Package Quantity | 1 |
