Medium-Voltage Fuse, JCL-B Series, 390A, Time-Delay, 4800V AC, Bolt-On
| Item | Medium-Voltage Fuse |
|---|---|
| Series | JCL-B |
| Amps | 390A |
| Speed | Time-Delay |
| AC Voltage Rating | 4800V AC |
| DC Voltage Rating | Not Rated |
| Body Style | Bolt-On |
| Visual Indication | Indicating |
| Interrupt Rating | 50kA at 4800V AC, 80kA at 4800V AC |
| Body Material | Fiberglass |
| Diameter | 3-1/3 in |
| Length | 19-1/4 in |
| Equivalent Brand and Series | Bussmann JCL-B |
| Equivalent Series | JCL-B |
| Fits Fuse Block Style | Non-Rejection |
| Standards | UL Recognized (Guide MSSS2, File E96676) |
| Class | R-Rated |
| Element | Dual |
| Package Quantity | 1 |
