Midget Fuse, C14 Series, 8A, 690V AC, Non-Indicating, 120kA
| Series | C14 |
|---|---|
| Amps | 8A |
| AC Voltage Rating | 690V AC |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 120kA |
| Body Style | Cylindrical |
| Diameter | 14 mm |
| Length | 51 mm |
| Body Material | Ceramic |
| DC Voltage Rating | Not Rated |
| Item | Midget Fuse |
| Type | Fuses |
| Material | Ceramic body |
| Application | for industrial applications | for general purpose use |
| Connection | Ferrule end x ferrule end |
| Product Width | 14.3 mm |
| Mounting method | 14 x 51 mm CH Modular fuse holder |
| Breaking Capacity | 80 kA |
| Product Height | 14.3 mm |
| Fuse shape | Cylindrical |
| Product Length/Depth | 51 mm |
| Fuse Type | Cylindrical |
| Certifications | VDE |
| Package Quantity | 1 |
