Plug Fuse, TC Series, Time-Delay, 25A, 125V AC, Indicating, 10kA at 125V AC, 4 PK
| Item | Plug Fuse |
|---|---|
| Series | TC |
| Speed | Time-Delay |
| Amps | 25A |
| AC Voltage Rating | 125V AC |
| Visual Indication | Indicating |
| Interrupt Rating | 10 kA @ 125 V AC |
| Body Style | Screw-In |
| Body Material | Plastic |
| Equivalent Brand and Series | Bussmann TC |
| Fits Fuse Block Style | Edison |
| DC Voltage Rating | Not Rated |
| Element | Dual |
| Standards | CE, UL 248-11 Guide JFHR, CSA Class 1423-01, File 53787 |
| Length | 1.18 in |
| Diameter | 1.16 in |
| Equivalent Series | TC |
| Fuse Size | 1.18 in L x 1.16 in H x 1.16 in D |
| Mounting | Threaded |
| Weight | 0.5 lb |
| Package Quantity | 4 |
