Bloque de distribución de energía, 310A, 2P, 1P Primario, 600VCA
| Item | Power Distribution Block |
|---|---|
| Number of Poles | 2 |
| Max. Amps | 310 |
| Primary Connections/Pole | 1 |
| Primary Wire Range (AWG) | 3/8-16 x 1-7/16 Stud |
| Secondary Connection/Pole | 1 |
| Secondary Wire Range (AWG) | 3/8-16 x 1-7/16 Stud |
| Power Distribution Block Design | Open |
| Voltage Rating | 600V AC/DC |
| Depth | 3.32 in |
| Length | 4 in |
| Standards | CSA Class 6228-01, UL 1059 |
| Width | 3.6 in |
| Length (Straight Wireway) | 4 in |
| For Line Aluminum Wire Size - Maximum | Not Available |
| Maximum Current - Copper Conductor | 310 A |
| For Load Aluminum Wire Size - Maximum | Not Available |
| Load Side Stud Size | 1/4-20 x 9/16" |
| For Load Aluminum Wire Size - Minimum | Not Available |
| Line Side Connection Type | Stud |
| Line Side Stud Size | 3/8-16 x 1-7/16" |
| Overall Length | 3.98 in |
| Maximum Current - Aluminum Conductor | 310 A |
| Load Connections/Pole | 2 |
| UL 94 Flammability Rating | V-0 |
| Overall Width | 3.35 in |
| Minimum Operating Temperature | -4 deg F |
| Overall Depth | 3.22 in |
| Maximum Voltage | 600 V AC/DC |
| RoHS Compliant | Yes |
| Load Side Connection Type | Stud |
| Maximum Operating Temperature | 248 deg F |
| For Conductor Material | Aluminum, Copper |
| Number of Circuits | 2 |
| Line Connections/Pole | 1 |
| For Line Aluminum Wire Size - Minimum | Not Available |
| Weight | 1.19 lb |
| Package Quantity | 1 |
