Surge Protection Device, 1 Phase, 24V, 4 Poles, 4 Wires
| Item | Surge Protection Device |
|---|---|
| Mounting Style | DIN Rail |
| Phase | 1 |
| Voltage | 24 V |
| Number of Poles | 4 |
| Voltage Protection Rating | 102V (L-L), 66V (L-G) |
| Number of Wires | 4 Wires |
| Modes of Protection | L-G, L-L |
| Max. Surge Current Per Mode | 2.5 kA |
| Max. Surge Current per Phase | 2.5 kA |
| Nominal Discharge Current | 10 kA |
| Modular | Yes |
| Filtering | No |
| Max. Continuing Operating Voltage | 33V DC |
| IP Rating | IP20 |
| Enclosure Material | Polyamide |
| Length | 3.54 in |
| Depth | 2.83 in |
| Width | 0.47 in |
| Wire Gauge | 28 to 12 AWG |
| Modular / Nonmodular | Modular |
| Standards | EN 61643-21, IEC 61643-21, UL 497B |
| Lightning Impulse Current | 10 kA |
| System Connection | Series |
| Amps | 0.75 |
| Min. Operating Temp. | -40 deg F |
| Max. Operating Temp. | 176 deg F |
| Color | Gray |
| Type | Surge arrestor |
| Includes Surge Counter | No |
| Mounting Method | DIN rail L-G |
| Operating Temperature | -40 to 80 °C |
| Certifications | UL 94V0 |
| Used with | Data signal |
| Special Features | Technology type spark-gap |
| Package Quantity | 1 |
