Circuit Breaker, CHT Series, 15A, 1 Pole, 120/240V AC, 10kA
| Item | Circuit Breaker |
|---|---|
| Series | CHT |
| Amps | 15A |
| Number of Poles | 1 |
| AC Voltage Rating | 120/240V AC |
| Circuit Breaker Mounting Style | Plug In |
| Max. AIR Rating | 10kA |
| Width | 3.2 in |
| Depth | 0.7 in |
| Height | 2.6 in |
| DC Voltage Rating | Not Rated |
| For Use With | Type CH Loadcenters |
| Interrupt Rating | 10 kA |
| Min. Wire Size | 14 AWG (Cu/Al) |
| Standards | UL Listed |
| Max. Wire Size | 8 AWG (Cu/Al) |
| Package Quantity | 1 |
