Unidad térmica Cutler-Hammer, de 1.79 a 2.9A, paquete de 3.
| Item | Thermal Unit |
|---|---|
| Full Load Amps | 1.79 to 2.9 |
| For Use With | NEMA Sizes 00 - 0 Series C, NEMA Sizes 1 - 2 Series B |
| FL Amp @ 3-Ph/ DP 20-30A/ Standard Enclosure | 1.79 to 2.9 |
| FL Amp @ 1-Ph/ Size 00,0,1/ Open & Large Enclosure | 1.79 to 2.9 |
| FL Amp @ 1-Ph/ Size 1P/ Open & Large Enclosure | 1.79 to 2.9 |
| Sensing Method | Bimetallic |
| FL Amp @ 3-Ph/ DP 50A/ Open & Large Enclosure | 1.79 to 2.9 |
| FL Amp @ 3-Ph/ DP 40A/ Open & Large Enclosure | 1.79 to 2.9 |
| FL Amp @ 3-Ph/ Size 00,0,1/ Open & Large Enclosure | 1.79 to 2.9 |
| FL Amp @ 1-Ph/ Size 00,0,1/ Standard Enclosure | 1.79 to 2.9 |
| FL Amp @ 3-Ph/ DP 40A/ Standard Enclosure | 1.79 to 2.9 |
| FL Amp @ 1-Ph/ DP 40A/ Standard Enclosure | 1.79 to 2.9 |
| FL Amp @ 1-Ph/ DP 20-30A/ Standard Enclosure | 1.79 to 2.9 |
| FL Amp @ 1-Ph/ Size 1P/ Standard Enclosure | 1.79 to 2.9 |
| FL Amp @ 3-Ph/ DP 20-30A/ Open & Large Enclosure | 1.79 to 2.9 |
| FL Amp @ 3-Ph/ Size 00,0,1/ Standard Enclosure | 1.79 to 2.9 |
| FL Amp @ 3-Ph/ DP 50A/ Standard Enclosure | 1.79 to 2.9 |
| FL Amp @ 1-Ph/ DP 50A/ Standard Enclosure | 1.79 to 2.9 |
| Product Length/Depth | 1.7 in |
| Special features | Used with starter sizes 00-0 (Series C), Sizes 1-2, 5-8 (Series B), IEC Sizes A-F (Series C), IEC Sizes G-K (Series B), IEC Sizes P-X, Z |
| Overload relay | 32 or 75A |
| Full load current range | 1.79A 2.16A 2.53A 2.9A Dial positions A B C D respectively |
| Certifications | CSA Certified |
| Type | Freedom/Definite Purpose Heater Pack |
| Trip Type | Standard Trip, Class 20 |
| Design | NEMA, IEC |
| Product Width | 1.8 in |
| Used with | Used with starter sizes 00-0 (Series C), Sizes 1-2, 5-8 (Series B), IEC Sizes A-F (Series C), IEC Sizes G-K (Series B), IEC Sizes P-X, Z |
| Product Height | 3.3 in |
| Product Name | Eaton Freedom NEMA heater coil |
| Compatible with Series | Freedom |
| Trip Class | 20 |
| Overload Protection Type | Thermal |
| Frame Size | S, G, H, J, K, P, R, T, V, W, X, Z |
| Full Load Current | 1.79 to 2.9 A |
| NEMA Size | 1, 2, 0, 00, 5, 6, 7, 8 |
| Package Quantity | 3 |
