Relevador de control IEC, 4NC, 24VCD, 16A.
| Item - Relay | IEC Style Control Relay |
|---|---|
| Coil Volts | 24 V DC |
| AC Contact Rating - Relay | 6A @ 240V |
| DC Contact Rating - Relay | 10 A @ 24 V |
| Number of Pins - Relay | 10 |
| Contact Form - Relay | (4) SPST-NO |
| Mounting - Relay | DIN Rail |
| Body Depth - Relay | 2.95 in |
| Response Time | 12 msec (Opening Delay), 31 msec (Closing Delay) |
| Contact Material | Silver Tin Oxide Alloy |
| Overall Height - Relay | 2.68 in |
| Mounting | Din Rail |
| Coil Rating | 3W |
| Hz | Not Applicable |
| Body Width - Relay | 1.77 in |
| Contact Amp Rating (Resistive) | 16 A |
| Contact Form | 4NO |
| Features | 4-Pole Configurations, Available with Screw or Spring Cage Terminals, IP20 Finger and Back-of-Hand Proof |
| Power Consumption - Relay | 3 W |
| Item | IEC Control Relay |
| Body Height - Relay | 2.68 in |
| Standards | UL Listed |
| Coil | 24 Vdc |
| Frame size | 45 mm |
| Product Length/Depth | 4 in |
| Coil voltage | 24 V DC |
| Certifications | UL Listed |
| Type | relay |
| Contact configuration | 4 NO |
| Rated operational current | 4 A at 380/400/415 V |
| Conventional thermal current | 10A |
| Product Height | 2 in |
| Product Width | 3-1/2 in |
| Terminals | Screw terminals |
| Product Name | Eaton XT IEC control relay |
| Power Consumption | 3 W |
| Maximum Operating Temperature | 140 deg F |
| Mechanical Operating Durability (AC) | 20,000,000 |
| Number of Pins | 10 |
| Contact Rating (AC) | 6 A @ 240V |
| Body Depth | 2.97 in |
| Mounting Style | DIN Rail |
| Input Voltage | 24V DC |
| Compatible with Series | Control Relays |
| IP Rating | IP20 |
| Electrical Connection | Screw Terminal |
| NEMA Size | Not Applicable |
| Overall Height | 2.68 in |
| For Use With | Contactors, Starters |
| Body Height | 2 in |
| Frequency | 60 Hz |
| Contact Rating (DC) | 10 A @ 24V |
| Mechanical Operating Durability (DC) | 20,000,000 |
| Minimum Operating Temperature | -13 deg F |
| Weight | 0.5 lb |
| Relay Style | IEC |
| Current Rating | 10 A |
| Body Width | 1.77 in |
| Package Quantity | 1 |
