Operador de joystick, iluminado, amarillo, 22mm
| Item | Joystick Operator |
|---|---|
| Size | 22.5 mm |
| Action | Momentary |
| Bezel | Silver |
| Product Height | 2-1/2 in |
| Illumination | Non-illuminated |
| Button color | Black |
| Product Length/Depth | 3 in |
| Product Width | 2-1/2 in |
| Environmental rating | IP67, IP69K, NEMA 4X, NEMA 21 |
| Type | Joystick |
| Certifications | CSA Certified |
| Compliances | CE Marked |
| Actuator function | Momentary |
| Series | M22 |
| Number of positions | 2 |
| Actuator | Joystick |
| Light Color | White |
| Lens Color | Yellow |
| Product Name | Eaton M22 modular pushbutton |
| Operating Cycles | 100,000 Hours of operation |
| Voltage Rating | dc, 12-30 Vac |
| Mushroom Head Diameter | Not Applicable |
| Operator Illumination | Illuminated |
| Legend | Not Applicable |
| Overall Height | 1 in |
| Lamp Voltage - Maximum | 30 V AC/DC |
| Legend Color | Not Applicable |
| Panel Cutout Diameter | 22 mm |
| Legend Background Color | Not Applicable |
| Push Button Style | Flush |
| Head Color | Yellow |
| Product Type | Push Button Operators |
| Number of Operators | 1 |
| Lamp Type | LED |
| Maintained Action Release | Not Applicable |
| Package Quantity | 1 |
