Load Centre Mounting Lug, 120/240V, 125A, 1 Poles
| Item | Load Centre Mounting Lug |
|---|---|
| Voltage | 120/240V |
| Amps | 125A |
| Number of Poles | 1 |
| Max. Wire Size | 2/0 AWG |
| Min. Wire Size | 6 AWG |
| Type | MLO |
| Bus material | Aluminum |
| NEMA rating | NEMA 1 |
| Wire size | #6-2/0 AWG Cu/Al |
| Interrupt rating | 10 kAIC |
| Enclosure | NEMA 1 |
| Product Length/Depth | 16-3/4 in |
| Cover | Cover included |
| Number of wires | Two hots, neutral and ground |
| Certifications | UL 67 |
| Number Of Circuits | 24 |
| Mounting | Surface, flush |
| Product Width | 14.31 in |
| Product Weight | 16.1 lb |
| Enclosure Material | Metallic |
| Number Of Spaces | 12 |
| Phase | Single-phase |
| Used with | Type BR 1-inch breakers |
| Product Height | 3.88 in |
| Package Quantity | 1 |
