Miniature Circuit Breaker, FAZ-NA Series, 16A, 1 Pole, 277/480V AC, 10kA, D Curve
| Item | Miniature Circuit Breaker |
|---|---|
| Series | FAZ-NA |
| Amps | 16A |
| Number of Poles | 1 |
| AC Voltage Rating | 277/480V AC |
| Phase | 1 |
| Circuit Breaker Mounting Style | DIN Rail |
| Max. AIR Rating | 10kA |
| Trip Type | Thermal Magnetic |
| Terminal Connection | Lug |
| Frame Size | 40A |
| Width | 0.71 in |
| Depth | 1 in |
| Height | 3 in |
| DC Voltage Rating | 48V DC |
| Curve Type | D |
| Min. Wire Size | 18 AWG |
| Max. Wire Size | 6 AWG |
| Standards | ABS, CSA Certified, IEC 60947 , RoHS, UL 489 Listed, VDE |
| Application | Air Conditioning, Computers, Convenience Receptacle Circuits, HACR Equipment (Heating, Motor Control Circuits, Refrigeration) (Internal/External), Relays, UPS |
| Length (Straight Wireway) | 3 in |
| Length | 3 in |
| Mounting | Din Rail |
| Package Quantity | 1 |
