Molded Case Circuit Breaker, EG Series, 100A, 3 Pole, 347/600V AC, 35kA at 240V AC
| Item | Molded Case Circuit Breaker |
|---|---|
| Series | EG |
| Amps | 100A |
| Number of Poles | 3 |
| AC Voltage Rating | 347/600V AC |
| Circuit Breaker Type | Standard |
| Phase | 3 |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Free Standing |
| Max. AIR Rating | 35kA at 240V AC |
| Trip Type | Thermal Magnetic |
| Instantaneous Trip | Fixed |
| Terminal Connection | Line, Load Lug |
| Phase Connection | ABC |
| Frame Size | 125A, EG |
| Width | 3 in |
| Depth | 2.99 in |
| Height | 5-1/2 in |
| DC Voltage Rating | 250V DC |
| Standards | CSA Certified, IEC Rated, UL Listed |
| Min. Wire Size | 14 AWG |
| High Amp Trip Setting | 125 A |
| For Use With | Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse |
| Low Amp Trip Setting | 15 A |
| Max. Wire Size | 1/0 AWG |
| Interrupt Rating | 18 kAIC at 600Y/347 Vac;25 kAIC at 480 Vac;35 kAIC at 240 Vac |
| Max. Operating Temp. | 158 deg F |
| Min. Operating Temp. | -4 deg F |
| Compliances | CE Marked |
| Certifications | CSA Certified;IEC Rated;UL Listed |
| Product Name | Eaton Series G molded case circuit breaker |
| Frequency Rating | 50/60 Hz |
| Mounting | Free Standing |
| Package Quantity | 1 |
