Sensor fotoeléctrico, cilíndrico, reflectante
| Item | Cylindrical Photoelectric Sensor |
|---|---|
| IP Rating | 69K |
| Operating Mode - Photoelectric Sensor | Dark On, Selectable Light On |
| Max. Load Current | 300 mA |
| Operating Frequency | 500 Hz |
| Features | Forward Viewing, Short Circuit Protection |
| Operating Temp. Range | -40 to 70 deg C |
| Standards | CE Approval, CUL Listed, UL Listed |
| Power Requirement - Cylindrical Photoelectric Sensor | 20 to 264V AC/15 to 30V DC |
| Circuit Type - Cylindrical Photoelectric Sensor | NPN |
| Length - Cylindrical Photoelectric Sensor | 66 mm |
| Max. Sensing Distance - Cylindrical Photoelectric Sensor | 7.6 m |
| Sensing Method - Cylindrical Photoelectric Sensor | Retroreflective |
| Min. Object Size | Adjustable By Changing Gain |
| Diameter - Cylindrical Photoelectric Sensor | 18 mm |
| Light Source | Red LED |
| Body Material | Solid Polyurethane |
| Electrical Connection - Cylindrical Photoelectric Sensor | 4-Pin Micro Connector |
| Response Time (ms) | 10 |
| NEMA Rating | 1, 12, 13, 2, 3, 4, 4X, 6 |
| Input voltage | 20-264 Vac at 50/60 Hz, 15-30 Vdc (NPN) |
| Maximum DC current | 300 mA |
| Product Width | 0.47 in |
| Number of pins | 4 |
| Certifications | UL Recognized |
| Enclosure Material | Polyurethane foam |
| Sensor type | Retroreflective |
| Maximum AC current | 300 mA |
| Connection | Dual key micro |
| Product Length/Depth | 2.2 in |
| Product Height | 0.71 in |
| Contact configuration | AC: L1 switched |
| Operating temperature - max | 158°F |
| Protection | Latching short circuit |
| LED indicator | Output ON |
| Contact Rating | 300 mA AC/DC at 20-264 Vac/15-30 Vdc |
| Environmental rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13, IP69K |
| Operating temperature - min | -40°F |
| Product Name | Eaton Comet 18mm tubular photoelectric sensor |
| Package Quantity | 1 |
