Sensor fotoeléctrico, cilindro, reflectante.
| Item | Cylindrical Photoelectric Sensor |
|---|---|
| IP Rating | 69K |
| Circuit Type | NPN/PNP |
| Width | 3.74 in |
| Operating Mode - Photoelectric Sensor | Dark On, Selectable Light On |
| Depth | 0.47 in |
| Max. Load Current | 250 mA |
| Operating Frequency | 500 Hz |
| Electrical Connection | 4-Pin Micro Connector |
| Response Time | 1 msec |
| Shape | Cylindrical |
| Diameter - Cylindrical Photoelectric Sensor | 18 mm |
| Standards | CE Approval, CUL Listed, UL Listed |
| Circuit Type - Cylindrical Photoelectric Sensor | NPN, PNP |
| Min. Object Size | Adjustable By Changing Gain |
| Light Source | Red LED |
| Length - Cylindrical Photoelectric Sensor | 66 mm |
| Sensing Method - Cylindrical Photoelectric Sensor | Retroreflective |
| Sensing Method | Retroreflective |
| Length | 2.6 in |
| Response Time (ms) | 1 |
| Power Requirement - Cylindrical Photoelectric Sensor | 10 to 30 V DC |
| Diameter | 18 mm |
| Electrical Connection - Cylindrical Photoelectric Sensor | 4-Pin Micro Connector |
| Power Requirement | 10 to 30VDC |
| Max. Sensing Distance - Cylindrical Photoelectric Sensor | 7.6 m |
| NEMA Rating | 1, 12, 13, 2, 3, 4, 4X, 6 |
| Operating Temp. Range | -40 to 70 deg C |
| Max. Sensing Distance | 7,600 mm |
| Operation Mode | Dark On, Selectable Light On |
| Features | Forward Viewing, Short Circuit and Overload Protection |
| Body Material | Solid Polyurethane |
| Connection type | Plug-in connection M12 x 1 |
| Load current | Max. 100 mA (Ie, PNP) |
| Switching distance - max | 0 mm |
| Sensor type | Retroreflective |
| Connection | M12 |
| Switching voltage of OSSD at state high | 0 V |
| Voltage rating - max | 30 V |
| Operational current (Ib) in the switched state at 24 V DC | 30 A |
| Switching Frequency | 500 Hz |
| Switching output type | PNP |
| Electric connection type | Plug-in connection |
| Type | Optical sensors |
| Number of outputs (protected semiconductor) | 0 |
| Rated switching distance (Sn) | 7,600 mm |
| Input voltage | 10-30 Vdc |
| Optical surface material | Plastic |
| Certifications | cUL Recognized |
| Functions | Reflected-light beam |
| Number of outputs (semiconductor with signaling function) | 2 |
| Contact Rating | 100 mA PNP, 250 mA NPN at 10-30 Vdc |
| Contact configuration | NPN and PNP open collector |
| Product Length/Depth | 127 mm |
| Product Width | 152.4 mm |
| Output current at protected output - max | 0 mA |
| Number of contact energized outputs with signalling function | 0 |
| Enclosure Material | Polyurethane foam |
| Environmental rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13, IP69K |
| Sensor length | 66 mm |
| Sensor material | Insulated material |
| Operating mode | Switching principle: Adjustable bright/dark switching |
| Operating temperature - min | -40°F |
| Protection | Auto reset short circuit |
| Number of pins | 4 |
| Rated control supply voltage (Us) at AC, 60 Hz - min | 0 V |
| Ambient operating temperature - min | -40°C |
| Sensing mode | Light-/dark switching |
| Light dot size | 0 mm² |
| Rated control supply voltage (Us) at DC - min | 10 V |
| Wavelength of the sensor | 0 nm |
| Voltage type | DC |
| Enclosure type | Cylinder, screw-thread |
| Light type | red light |
| Adjustment type | Manual adjustment |
| Degree of protection | NEMA 1 |
| Maximum DC current | 100 mA, 250 mA |
| Rated control supply voltage (Us) at AC, 60 Hz - max | 0 V |
| Rated control supply voltage (Us) at DC - max | 30 V |
| Diameter sensor | 18 mm |
| Transmission range of the safety field | 0 m |
| Rated control supply voltage (Us) at AC, 50 Hz - min | 0 V |
| Switch function type | Programmable/configurable |
| Number of outputs (protected contact energized) | 0 |
| Output current (mA) - max | 100 mA |
| Operating temperature - max | 158°F |
| Product Height | 50.8 mm |
| Shock Resistance | 100 g, Mechanical, Shock duration 3 ms |
| Reflector distance - min | 0 mm |
| Rated control supply voltage (Us) at AC, 50 Hz - max | 0 V |
| Ambient operating temperature - max | 70°C |
| LED indicator | Output ON |
| Product Name | Eaton Moeller® series E58 Diffuse reflective sensor |
| Package Quantity | 1 |
