Sensor fotoeléctrico, cilíndrico, difuso.
| Item | Cylindrical Photoelectric Sensor |
|---|---|
| IP Rating | 69K |
| Circuit Type | NPN |
| Width | 7.3 in |
| Depth | 0.47 in |
| Operating Mode - Photoelectric Sensor | Dark On, Selectable Light On |
| Max. Load Current | 300 mA |
| Operating Frequency | 500 Hz |
| Electrical Connection | 2m cable |
| Max. Sensing Distance - Cylindrical Photoelectric Sensor | 100 mm |
| Sensing Method - Cylindrical Photoelectric Sensor | Diffuse |
| Max. Sensing Distance | 100 mm |
| Diameter | 18 mm |
| NEMA Rating | 1, 12, 13, 2, 3, 4, 4X, 6 |
| Body Material | Solid Polyurethane |
| Operation Mode | Dark On, Selectable Light On |
| Power Requirement | 20 to 264VAC/15 to 30VDC |
| Sensing Method | Diffuse |
| Response Time | 10 msec |
| Response Time (ms) | 10 |
| Electrical Connection - Cylindrical Photoelectric Sensor | Cable |
| Operating Temp. Range | -40 to 70 deg C |
| Diameter - Cylindrical Photoelectric Sensor | 18 mm |
| Light Source | Red LED |
| Features | Right Angle Viewing, Short Circuit Protection |
| Power Requirement - Cylindrical Photoelectric Sensor | 20 to 264V AC/15 to 30V DC |
| Shape | Cylindrical |
| Length | 3.02 in |
| Length - Cylindrical Photoelectric Sensor | 77 mm |
| Min. Object Size | Adjustable By Changing Gain |
| Standards | CE Approval, CUL Listed, UL Listed |
| Circuit Type - Cylindrical Photoelectric Sensor | NPN |
| Certifications | UL Recognized |
| Cord length | 79.2 ft |
| Operating mode | Background suppression |
| Sensor type | Back ground suppression |
| Switch type | Photoelectric |
| LED indicator | Output status: red |
| Operating temperature - min | -40°F |
| Input voltage | 20-264 Vac, 15-30 Vdc |
| Operating temperature - max | 158°F |
| Product Width | 0.71 in |
| Contact configuration | AC: L1 switched |
| Maximum DC current | 300 mA |
| Environmental rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K |
| Product Length/Depth | 0.6 in |
| Protection | Latching short circuit |
| Cable type | Polyvinyl Chloride |
| Contact Rating | 300 mA AC/DC at 20-264Vac/15-30Vdc |
| Connection | 6.6 ft (2 m) cable |
| Compliances | CE Marked |
| Product Height | 3.02 in |
| Enclosure Material | Polyurethane foam |
| Maximum AC current | 300 mA |
| Product Name | Eaton Comet 18mm tubular photoelectric sensor |
| Package Quantity | 1 |
