Kit de actualización para interruptor de arranque magnético inverso, sin caja clasificada NEMA, 120V AC, 3 polos, 1NA.
| Item | Magnetic Motor Starter |
|---|---|
| Overload Relay Amp Setting | 60 to 300 A |
| Coil Volts | 120V AC |
| Enclosure NEMA Rating | No Enclosure |
| Auxiliary Contact Form | 1NO |
| HP @ 3 Phase - 240V | 100 HP |
| Starter Type | NEMA Style |
| Action | Reversing |
| Amps AC | 270 A |
| NEMA Size | 5 |
| Number of Poles | 3 |
| HP @ 3 Phase - 480V | 200 HP |
| Standards | UL Listed |
| Includes | Mounting Plate, Universal Overload Relay Reset |
| Hz | 50/60 |
| Width | 12-1/2 in |
| Depth | 7.78 in |
| Features | Universal NEMA Retrofit Starter Kit |
| Height | 13.12 in |
| HP @ 3 Phase - 208V | 75 HP |
| HP @ 3 Phase - 575V | 200 hp |
| Thermal Unit Code | Not Applicable |
| Weight | 41 lb |
| Coil | 120 Vac |
| Product Height | 19 in |
| Product Width | 15 in |
| Product Name | Eaton Freedom NEMA motor control starter |
| Amperage Rating | 60-300A |
| Accessories | Freedom NEMA |
| Certifications | UL Listed |
| Product Length/Depth | 25 in |
| Coil Voltage | 120V AC |
| Number of Auxillary Contacts | 1 |
| NEMA Enclosure Rating | No Enclosure |
| Operator Function | Not Applicable |
| Operator | None |
| Horsepower @ Three Phase - 240V AC | 100 HP |
| Horsepower @ Single Phase - 120V AC | Not Rated |
| Frame Size | S5 |
| Starter Style | NEMA |
| Overall Height | 9.2 in |
| Series | Freedom |
| Overall Width | 11-1/2 in |
| Mounting Style | Surface |
| Auxiliary Contact Module Capacity | 6 |
| Overload Protection Type | Electronic |
| Trip Class | 10A/10/20/30 |
| Includes Auxiliary Contacts | Yes |
| Horsepower @ Three Phase - 480V AC | 200 HP |
| Maximum Voltage Rating | 600 V AC |
| Maximum Overload Relay Current Setting | 300 A |
| Hazardous Location Specification | Not Applicable |
| Minimum Overload Relay Current Setting | 60 A |
| Overall Depth | 21 in |
| Horsepower @ Three Phase - 208V AC | 75 HP |
| Horsepower @ Three Phase - 600V AC | 200 HP |
| Horsepower @ Single Phase - 240V AC | Not Rated |
| Current AC | 300 A |
| Reversing Capability | Non-Reversing |
| Frequency | 50/60 Hz |
| Phase | Three |
| Mounting Postion | Horizontal |
| Package Quantity | 1 |
