Interruptor selector de mango corto, negro, 2 posiciones, 22 mm.
| Item | Short-Handled Selector Switch |
|---|---|
| Voltage | 85 to 264V AC/DC |
| Color | Blue |
| Action | Maintained |
| Bezel | Silver |
| Size | 22.5 mm |
| Width | 1.18 in |
| NEMA Rating | 4X, 13 |
| IP Rating | IP69K, IP67, IP66 |
| Type | Indicating Light |
| Standards | CSA Certified |
| Length | 1.46 in |
| Height | 2.22 in |
| Certifications | CCC Marked;CSA Certified;Lloyd's Register Certified |
| Actuator Function | Maintained |
| Environmental Rating | IP66, NEMA 4X, NEMA 13 |
| Number of Positions | 2 |
| Product Name | Eaton M22 pushbutton operator |
| Illumination | Non-illuminated |
| Inscription | AUTO HAND |
| Product Width | 5 in |
| Button Color | Black |
| Product Height | 1-1/2 in |
| Actuator | Rotary |
| Series | M22 |
| Compliances | CE Marked;Bureau Veritas;GoST-R |
| Product Length/Depth | 7 in |
| Operating Cycles | 100000 |
| Hazardous Location Specification | Not Rated |
| Overall Depth | 2.78 in |
| Operator Head Material | Polycarbonate |
| Switch Function @ 3rd Position | No Third Position |
| Includes Operator Key | Not Applicable |
| Key Removal Position | Not Applicable |
| NEMA Enclosure Rating | 13, 4, 12, 3, 4X, 3R, 1, 2 |
| Bezel Material | Silver |
| Overall Height | 1 in |
| Operator Head Type | Short-Handled Knob |
| Cam | No Cam Needed |
| Switch Function @ 1st Position | On |
| Operator Head Color | Black |
| Operator Illumination | Non-Illuminated |
| Switch Function @ 2nd Position | On |
| Switch Function @ 4th Position | No Fourth Position |
| Panel Cutout Diameter | 22 mm |
| Overall Width | 1 in |
| Package Quantity | 1 |
