Shunt Trip, FAZ Circuit Breakers and Supplementary Protectors, 12/110V AC, 1A
| Item | Shunt Trip |
|---|---|
| For Use With | FAZ Circuit Breakers and Supplementary Protectors |
| Voltage | 12/110V AC |
| Amps | 1A |
| AC Voltage Rating | 12/110V AC |
| Frame Type | 63A/FAZ |
| DC Voltage Rating | 12/60V DC |
| Includes | Red/Green Position Indicator |
| Max. Operating Temp. | 167 deg F |
| Min. Operating Temp. | -40 deg F |
| Type | Accessories |
| Product Height | 1 in |
| Product Width | 1 in |
| Product Length/Depth | 1 in |
| Certifications | CSA Std. C22.2 No.235 |
| Special features | Used with UL 1077 Industrial Miniature Circuit Breakers |
| Product Weight | 1 lb |
| Product Name | Eaton FAZ shunt release |
| Package Quantity | 1 |
