Surge Protection Device, 1 Phase, 24V DC, 1 Poles, 2 Wires, 6kA
| Item | Surge Protection Device |
|---|---|
| Mounting Style | Panel |
| Phase | 1 |
| Voltage | 24 V |
| Number of Poles | 1 |
| Number of Wires | 2 Wires |
| Filtering / Nonfiltering | Filtering |
| Max. Surge Current Per Mode | 6 kA |
| Max. Surge Current Per Phase | 6 kA |
| Nominal Discharge Current | 3 kA |
| Short Circuit Current Rating | 10 kA |
| Modular | Yes |
| Filtering | Yes |
| Max. Continuing Operating Voltage | 30V AC/DC |
| Enclosure NEMA Rating | NEMA 1 |
| Enclosure Material | Polycarbonate |
| Length | 4.77 in |
| Depth | 1-1/4 in |
| Width | 2.47 in |
| Wire Gauge | 12 AWG |
| Modular / Nonmodular | Modular |
| Noise Attenuation | 40dB |
| Type | Powerline filter |
| Includes Surge Counter | No |
| Protection filtering | Critical protection with filtering, EMI filter |
| Mounting Method | DIN rail |
| Amperage Rating | 10A |
| Certifications | CSA Certified |
| Series | AEGIS |
| Frequency Rating | 50 to 60 Hz |
| Used with | Single-phase, two- or three-wire grounded systems |
| Package Quantity | 1 |
