The Cutler Hammer CHGF115 is a 1 Pole molded case ground fault circuit breaker with a current rating of 15 Amps and a voltage rating of 120V. It has an interrupting rating of 10kAIC at 120V. The CHGF115 has a plug-in connection type and includes long time and instantaneous trip functions.
| Brand | Eaton/Cutler-Hammer |
|---|---|
| Series | CH |
| Amperage | 15 |
| Voltage | 120V |
| Poles | 1 |
| Phase | 1 |
| Mounting Type | Plug-On |
| Interrupting Rating | 10kAIC at 120V |
| Frame Type | CH |
| Connection Type | Plug-In |
| Protection | Thermal Magnetic |
| Functions | LI - Long-Time and Instantaneous Trip |
| Temperature Rating | 40 °C |
| Circuit Breaker Type | GFCI |
| Breaker Feature | Standard Interrupting Capacity |
| Mpn | CHGF115 |
