The Eaton ED2200 is a 2 Pole thermal magnetic molded case circuit breaker with a current rating of 200 Amps and a voltage rating of 240VAC, 125VDC. It has an interrupting rating of 65kAIC at 240VAC. The ED2200 has a bolt-on connection type and includes long time and instantaneous trip functions.
| Brand | Eaton/Cutler-Hammer |
|---|---|
| Series | C |
| Amperage | 200 |
| Voltage | 240VAC, 125VDC |
| Poles | 2 |
| Phase | 1 |
| Mounting Type | Bolt-On |
| Approval | UL, CSA, CE |
| Interrupting Rating | 65kAIC at 240VAC |
| Frame Type | ED |
| Connection Type | Bolt-On |
| Protection | Thermal Magnetic |
| Functions | LI - Long-Time and Instantaneous Trip |
| Terminal Connection | Line and Load Side Lug |
| Length (in) | 3.38 |
| Width (in) | 2.75 |
| Height (in) | 6 |
| Circuit Breaker Type | ED |
| Mpn | ED2200 |
| Upc | 786679456224 |
| Gtin | 786679456224 |
