The Westinghouse EHB1070 is a 1 Pole thermal magnetic molded case circuit breaker with a current rating of 70 Amps and a voltage rating of 120/277VAC. It has an interrupting rating of 10kAIC at 277V. The EHB1070 has a bolt-on connection type and includes long time and instantaneous trip functions.
| Brand | Eaton/Cutler-Hammer |
|---|---|
| Series | EHB |
| Amperage | 70 |
| Voltage | 120/277VAC |
| Poles | 1 |
| Phase | 1 |
| Mounting Type | Bolt-On |
| Contactor Type | Magnetic |
| Interrupting Rating | 10kAIC at 277V |
| Frame Type | EHB |
| Connection Type | Bolt-On |
| Protection | Thermal Magnetic |
| Functions | LI - Long-Time and Instantaneous Trip |
| Terminal Connection | Load Side Lug |
| Temperature Rating | 40 °C |
| Mpn | EHB1070 |
