1 INCH SHRINK FIT GP - BTKV 50
| Series | HSK40A |
|---|---|
| Item | Shrink Fit Tool Holder and Adapter |
| Coolant Fed | Coolant Through |
| Shank Dia. | 33 mm |
| Hole Dia. | 25.4 mm |
| For Use With | Carbide and HSS Tools |
| Nose Dia. | 33 mm |
| List Number | BTKV50BHPVTT100400 |
| Taper Size | BTKV50 |
| Projection | 101.6 mm |
| Max. Speed | 15,000 rpm |
| Overall Length | 203.4 mm |
| Features | Balanceable, End Axial Adjustment |
| Tool Depth | 47 mm |
| Compatible with Product Type | Carbide and HSS Cutting Tools |
| Balanced to RPM | G 6.3 @ 15,000 rpm |
| Measurement System | Fractional Inch |
| Standards | ANSI, ISO, DIN 69893 |
| Package Quantity | 1 |
