1 INCH SHRINK FIT GP - CVKV 50
| Series | HSK63A |
|---|---|
| Hole Dia. | 25.4 mm |
| Coolant Fed | Coolant Through |
| Item | Shrink Fit Tool Holder and Adapter |
| Shank Dia. | 44 mm |
| Nose Dia. | 44 mm |
| List Number | CVKV50BHPVTT100400 |
| For Use With | Carbide and HSS Tools |
| Projection | 101.6 mm |
| Taper Size | CVKV50 |
| Max. Speed | 15,000 rpm |
| Overall Length | 203.2 mm |
| Features | Axial Adjustment: End, Balanceable, Fine Tune with Optional M6 Set Screws |
| Compatible with Product Type | Carbide and HSS Cutting Tools |
| Tool Depth | 47 mm |
| Balanced to RPM | G 2.5 @ 15,000 rpm |
| Measurement System | Fractional Inch |
| Standards | ANSI, DIN 69893, ISO |
| Package Quantity | 1 |
