Retention Knob, CAT40, 5/8"-11
| Item | Collet Chuck |
|---|---|
| Dimension Type | Fractional Inch |
| Shank Type | Cylindrical |
| Overall Length | 2-1/4 in |
| Taper Size | CV50 |
| Collet Series | ER40 |
| Shank Dia. | 2-3/4 in |
| Min. Collet Capacity | 0.12 in |
| Max. Collet Capacity | 1 in |
| Projection | 1.692 in |
| Nut Dia. | 1.811 in |
| Bore Depth | 2.24 in |
| Nose Dia. | 46 mm |
| Coolant Fed | Coolant Through |
| Standards | ANSI B5.50, DIN 6499 |
| Features | Grip 2:1 |
| ANSI Code | CV50SER40169 |
| Number of Coolant Holes | 2 |
| Shank Thread Size | 1"-8 |
| Application | Drilling |
| For Shank Type | Cylindrical |
| Shank Type - Machining | Cylindrical |
| Cutting Direction | Neutral |
| Compatible Collet Series | ER40 |
| Nut Diameter | 1.811 in |
| Shank Diameter | 2-3/4 in |
| Package Quantity | 1 |
