Shrink Fit Tool Holder, U3, CAT40
| Item | Collet Chuck |
|---|---|
| Shank Type | Taper |
| Dimension Type | Fractional Inch |
| Overall Length | 220.65 mm |
| Taper Size | CAT40 |
| Collet Series | ER32 |
| Shank Dia. | 20 mm |
| Projection | 80 mm |
| Nose Dia. | 33 mm |
| Coolant Fed | Coolant Through |
| Features | Maximum T.I.R. only 0.0001 in |
| Standards | DIN 6499 |
| ANSI Code | CVKV40ER32600 |
| Compatible with Product Type | Cutting Tools |
| Hole Dia. | 20 mm |
| Balanced to RPM | 25,000 RPM |
| Tool Depth | 52 mm |
| Cutting Direction | Neutral |
| Shank Diameter | 20 mm |
| Coolant Supply | Coolant Through |
| Package Quantity | 1 |
