Shrink Fit Tool Holder, U3, CAT50
| Series | Cat50 ShrinkFit |
|---|---|
| Taper | HSK63A |
| Item | Hydraulic Chuck |
| Bore Dia. | 2.4803 in |
| ANSI Number | HSK63AHC075400 |
| Nose Dia. | 41.6 mm |
| Shank Dia. | 19.05 mm |
| Overall Length | 133.6 mm |
| Balanced to RPM | G 2.5@25000 rpm |
| Standards | DIN 69893 |
| Coolant Fed | Coolant Through |
| Taper Size | HSK63 |
| Projection | 101.6 mm |
| Tool Depth | 41 mm |
| Hole Dia. | 19.05 mm |
| Shank Type - Machining | Cylindrical |
| Features | Side Axial Adjustment |
| For Use With | HSK63 Shank Tools |
| Style | Standard HP Line |
| Mounting Length | 41 mm |
| Package Quantity | 1 |
