Shrink Fit Tool Holder, U3, CV40
| Taper | HSK63A |
|---|---|
| Item | Hydraulic Chuck |
| Series | CV40 |
| Bore Dia. | 63 mm |
| Nose Dia. | 37.54 mm |
| ANSI Number | HSK63AHC16150M |
| Hole Dia. | 16 mm |
| Tool Depth | 39 mm |
| Projection | 150 mm |
| Taper Size | HSK63 |
| Shank Type - Machining | Cylindrical |
| Shank Dia. | 16 mm |
| Overall Length | 181.9 mm |
| Standards | DIN 69893 |
| Coolant Fed | Coolant Through |
| Features | Side Axial Adjustment |
| Balanced to RPM | G 2.5@25000 rpm |
| For Use With | HSK63 Shank Tools |
| Style | Standard HP Line |
| Mounting Length | 39 mm |
| Package Quantity | 1 |
