Shrink Fit Tool Holder, U3, CVKV40
| Item | Shrink Fit Tool Holder and Adapter |
|---|---|
| Taper Size | BT50 |
| Hole Dia. | 6 mm |
| Projection | 160 mm |
| Coolant Fed | Coolant Through |
| Overall Length | 261.8 mm |
| Shank Dia. | 21 mm |
| Balanced to RPM | G 6.3@15000 rpm |
| Nose Dia. | 21 mm |
| For Use With | Carbide and HSS Tools |
| List Number | BT50BHPVTT06160M |
| Features | Axial Adjustment - End, Balanceable -Fine Tune with Optional M6 Set Screws |
| Max. Speed | 15,000 rpm |
| Compatible with Product Type | Cutting Tools |
| Series | CVKV40 |
| Tool Depth | 26 mm |
| Standards | ANSI, ISO |
| Measurement System | Metric |
| Package Quantity | 1 |
