Shrink Fit Tool Holder, U3, HSK100A
| Series | HSK100A ShrinkFit |
|---|---|
| Taper | CV50 |
| Bore Dia. | 2-3/4 in |
| Item | Hydraulic Chuck |
| Nose Dia. | 53/64 in |
| ANSI Number | CV50HC075400 |
| Overall Length | 203.2 mm |
| Shank Type - Machining | Taper |
| Tool Depth | 1-27/64 in |
| Shank Dia. | 1/4 in |
| Hole Dia. | 1/4 in |
| Balanced to RPM | 25,000 RPM |
| Projection | 90 mm |
| Coolant Fed | Coolant Through |
| Standards | ANSI B5.50 |
| Taper Size | HSK100A |
| Features | Maximum T.I.R. only 0.0001 in |
| Package Quantity | 1 |
