30A Watertight Locking Plug 2P 3W 277VAC L7-30P YL
| Item - Plugs and Receptacles | Watertight Plug |
|---|---|
| Item | Watertight Locking Plug |
| Wiring Style | Standard |
| Shrouded / Non-Shrouded | Shrouded |
| Grade - Plugs and Receptacles | Industrial |
| Amps - Plugs and Receptacles | 30 |
| NEMA Plug Configuration - Plugs and Receptacles | L7-30P |
| Voltage - Plugs and Receptacles | 277V AC |
| Number of Poles | 2 |
| Number of Wires | 3 |
| Phase | Single |
| Special Features | Corrosion resistant |
| Antimicrobial | Yes |
| Corrosion Resistant | Yes |
| Material | Thermoplastic Elastomer |
| IP Rating | IP69K |
| Color - Plugs and Receptacles | Yellow, Orange |
| Amps | 30 |
| Voltage | 277VAC |
| Standards | ANSI/UL 498 File E17740, CSA Certified C22.2 No. 42, NSF/ANSI/3-A 14159-1 |
| HP | 3 |
| NEMA Rating | 4, 4X, 12, 6, 6P |
| NEMA Configuration | L7-30 |
| Grade | Industrial |
| Cord Size | 0.64 to 0.93 in |
| Color | Yellow |
| Market | Industrial |
| For Maximum Cable Diameter | 0.93 in |
| Housing Material | Elastomer |
| NEMA Plug Configuration | L7-30P |
| Horsepower Rating | 3 HP |
| Housing Color | Yellow |
| Resistance Properties | Antimicrobial, Corrosion Resistant |
| Voltage Rating | 277V AC |
| Current Rating | 30 A |
| Shrouded | Yes |
| For Minimum Cable Diameter | 0.64 in |
| Number of Blades | 3 |
| For Environment | Washdown |
| Device Type | Plug |
| Ideal Application | Any environment that requires a watertight seal of a plug and connector to prevent water ingress. Applications range from a construction site to an entertainment venue and a drop down connector in a food processing plant during a Washdown procedure. |
| UL | UL Listed to ANSI/UL 498, File E17740 |
| Blade Style | Locking |
| CSA | CSA Certified to CSA C22.2 No.42, File 31943 |
| Poles / Wires | 2P/3W |
| NSF | NSF/ANSI/3-A 14159-1 |
| Environmental Rating | Watertight |
| Sub Brand / Trademark | Perma-Kleen |
| Package Quantity | 1 |
